THE ENZYME-ASSISTED SYNTHESIS OF POLYMERIC NANOCOMPOSITES AND THEIR INVESTIGATIONS

Rugile Chmieliauskaite1, Natalija German2

1 Department of Chemistry and Bioengineering, Faculty of Fundamental Sciences, Vilnius Gediminas Technical University Vilnius Tech, Sauletekio ave.11, LT-10223, Vilnius, Lithuania

2 Division of Immunology, State Research Institute Center for Innovative Medicine, Santariskių g. 5, LT-08406, Vilnius, Lithuania

[email protected]

Last decades the interest of nano- and biotechnology's application in the diagnostics and the monitoring of compounds increased rapidly [1,2]. Electrochemical enzymatic biosensors are the most popular and widely used in clinical analysis, pharmaceuticals, food processing industries and environmental monitoring due to their specificity and sensitivity in complex systems [2]. Diabetes mellitus — the most common endocrine disorder of carbohydrate metabolism and is considered a chronic disease caused by improper regulation of glucose in the blood [2,3]. Usually high sensitivity and selectivity, the rapidity and the reversibility, the application and the excellent catalytic activities are characterized for electrochemical biosensors immobilized by enzyme and polymers [2,4,5].

The main aim of this research was to synthesize polymeric nanocompositions (PNC) with embedded glucose oxidase and to develop glucose biosensors immobilized by such PNC with following addition of enzyme. To achieve electron transfer between the solution and graphite rod electrode soluble mediator – phenazine methosulfate (PMS) was used. It was predicted that formed by enzyme-assisted polymerization polyaniline and polypyrrole nanocomposites are able to facilitate indirect electron transfer and has the positive effect on the sensitivity and selectivity of developed system [2,4,5]. The most suitable immobilization method by PNC and the kind of polymer were chosen in order to improve analytical characteristics of glucose biosensor during research. Cyclic voltammetry was used to investigate the reversibility of electrochemical reaction and the suitability of developed glucose biosensor. Meanwhile, another electrochemical method such as chronoamperometry was used for the investigations of analytical characteristics and the stability of the developed system. It was evaluated, that the addition of PMS is necessary, because in the absence of mediator no electron transfer is able. Although the presence of polypyrrole nancomposites on the surface of working electrode enhanced the glucose analytical signal the most, however the lower limit of detection was obtained in the presence of polyaniline nanocompositions. Enzyme-assisted PNC could be apply in the construction of electrochemical glucose biosensors and could be use in different diagnostic applications.

Figure 1
Fig. 1. Formed by enzyme-assisted polymerization polyaniline (on the left) and polypyrrole (on the right) solutions.

[1] F. Wang, S. Hu, Electrochemical sensors based on metal and semiconductor nanoparticles, Microchim Acta 165, 1-22 (2009).

[2] J. Lai, Y. Yi, P. Zhu, J. Shen, K. Wu, L. Zhang, J. Liu, Polyaniline-based glucose biosensor: A review, Journal of Electroanalytical Chemistry 782 138-153 (2016).

[3] E-H. Yoo, S.-Y. Lee, Glucose biosensors: An overview of use in clinical practice, Sensors 10: 4558-4576 (2010).

[4] N. German, A. Ramanaviciene, A. Ramanavicius, Formation and electrochemical evaluation of polyaniline and polypyrrole nanocomposites based on glucose oxidase and gold-nanostructures, Polymers 12, 3026 (2020).

[5] N. German, A. Ramanavicius, A. Ramanaviciene, Amperometric glucose biosensor based on electrochemically deposited gold nanoparticles covered by polypyrrole, Electroanalysis 29 1267-1277 (2017).
